Two-Way Optical Loss Test Set with ORL


These are the industry’s fastest and easiest to use Two-Way Optical Loss Test Sets (OLTS). Featuring true optically stabilised light sources which require no warm up, they display bi-directional average loss and Return Loss (ORL) in real time. The instrument can also be used as a source & meter, tone generator / detector, or high performance ORL meter. This is the ideal solution for measuring the splitter based PON access networks typically used in fiber to the home.

  • NEW “C” Series with USB Interface & new technology InGaAs detector
  • No warm up on source, meter & ORL
  • Very fast and easy to use
  • Real-time two way Autotest loss and ORL display at up to 4 wavelengths
  • Up to 4 Autotest CWDM source wavelengths on one port
  • 1 % meter accuracy & over 24 calibrated CWDM / DWDM wavelengths
  • Single mode or multimode options. The industry’s only multimode ORL meter
  • KITS™ software for acquisition, pass/fail and reporting
  • Ideal FTTx PON solution
  • Pass / Fail display
  • Large memory and 190 – 360 hr battery life
  • Supplied with metal free SC, ST, FC interchangeable connectors. Other options include LC connectors
  • Tone generator
